Kent CNC
Kent CNC is a renowned manufacturer of high-precision CNC machining solutions. Known for their exceptional quality and innovative designs, Kent CNC machines are used across various industries including aerospace, automotive, and general manufacturing. Their product range includes vertical and horizontal machining centers, turning centers, and advanced CNC solutions.
Kent CNC: Advanced Machining Solutions
Kent CNC is a renowned manufacturer of high-precision CNC machining solutions. Known for their exceptional quality and innovative designs, Kent CNC machines are used across various industries including aerospace, automotive, and general manufacturing. Their product range includes vertical and horizontal machining centers, turning centers, and advanced CNC solutions.
Established: 1979
Headquarters: Tustin, California, USA
Product Range: Vertical and horizontal machining centers, turning centers, CNC milling machines
Global Reach: Extensive distribution network serving industries worldwide
Industry Focus: Aerospace, automotive, defense, and general manufacturing
Kent CNC Vertical Machining Centers
Vertical Machining Centers - KVR Series
| Model | Travels (X, Y, Z) (inches) | Spindle Center to Column (inches) | Table Dimensions (inches) | Table Load (lbs) | Spindle RPM | Rapid Traverse (ipm) | Spindle Motor (hp) | CNC Control |
|---|---|---|---|---|---|---|---|---|
| KVR-2418/A | 24, 18.1, 18.9 | 19.7 | 30 x 18 | 660 | 10,000 | 1417 | 10 / 15 (7.5 / 11.2 KW) | Fanuc 0i-M (Heidenhein, Siemens, Mitsubishi, Fagor) |
| KVR-3618/A | 36, 19.7, 20.5 | 21.9 | 39.37 x 18.11 | 1540 | 10,000 | 1417 | 10 / 15 (7.5 / 11.2 KW) | Fanuc 0i-M (Heidenhein, Siemens, Mitsubishi, Fagor) |
| KVR-4020/A | 40, 19.7, 20.5 | 21.9 | 43.3 x 20.5 | 1760 | 10,000 | 1417 | 10 / 15 (7.5 / 11.2 KW) | Fanuc 0i-M (Heidenhein, Siemens, Mitsubishi, Fagor) |
Heavy Duty Vertical Machining Centers - Box Way
| Model | Travels (X, Y, Z) (inches) | Spindle Center to Column Surface (inches) | Table Dimensions (inches) | Table Load Capacity (lbs) | Spindle RPM BT-40 | Spindle RPM BT-50 | Rapid Traverse (ipm) | Spindle Motor BT50 (hp) | Max Tool Diameter (inches) | Max Tool Length (inches) | CNC Control |
|---|---|---|---|---|---|---|---|---|---|---|---|
| KVR-1065 | 40, 26, 24 | 27 | 24 x 47 | 1760 | 6000 | 4500 | 591 | 10 | BT50: 5 | BT50: 13.8 | Fanuc 0i / 18Mi |
| KVR-1268 | 50, 27, 24 | 28 | 24 x 60 | 2640 | 6000 | 4500 | 591 | 14.8 | BT50: 5 | BT50: 13.8 | Fanuc 0i / 18Mi |
| KVR-1580 | 60, 32, 28 | 33 | 28 x 63 | 4620 | 6000 | 4500 | 591 | 21 | BT50: 5 | BT50: 13.8 | Fanuc 0i / 18Mi |
Double Column Vertical Machining Centers - KFD/W Series
| Model | Distance Between Columns (inches) | Table Size (inches) | Max Table Load (tons) | Travels (X, Y, Z) (inches) | Spindle Taper / Speed / Power | Cutting Feedrate (ipm) | CNC Control |
|---|---|---|---|---|---|---|---|
| KFD-14 | 55 | 78 – 118 x 47 | 10 - 15 | 86 - 125 x 51 x 31 | CAT 50 – 6000 rpm – 22 hp / 34 hp + 2-stage gearbox | 393 | Fanuc 0i / 18Mi |
| KFD-21 | 84 | 78 – 196 x 70 | 12 - 20 | 86 - 204 x 82 x 31 | CAT 50 – 6000 rpm – 22 hp / 34 hp + 2-stage gearbox | 275 | Fanuc 0i / 18Mi |
| KFD-32 | 127 | 118 – 236 x 102 | 18 - 24 | 125 - 236 x 125 x 43 | CAT 50 – 6000 rpm – 22 hp / 34 hp + 2-stage gearbox | 236 | Fanuc 0i / 18Mi |
Kent CNC Lathe Specifications
CNC Lathes - KLR Series
| Model | Max Turning Diameter (inches) | Max Turning Length (inches) | Spindle Nose | Chuck Diameter (inches) | Spindle Speed (RPM) | Spindle Motor (HP) | Z-Axis Travel (inches) | X-Axis Travel (inches) | Machine Weight (lbs) |
|---|---|---|---|---|---|---|---|---|---|
| KLR-200 | 11.41 | 21.65 - 38.58 | A2-6 | 8 | 4000 | Up to 20 | 23.6 | 8.7 | 7925 - 11440 |
| KLT-2000 | 11.8 | 15.7 | A2-6 | 8 | 4500 | Up to 20 | 15.7 | 6.69 | 3300 |
| KLR-300 | 19.7 | 27.6 - 86.6 | A2-8 | 10 | 3500 | Up to 25 | 29.5 | 11.8 | 12133 - 19854 |
| KLR-360 | 21.6 | 24.8 | A2-11 | 12 | 2700 | Up to 30 | 29.5 | 10.8 + 1.2 | 13668 |
| KLR-400 | 26.8 | 43.3 - 157 | A2-11 | 15 | 2200 | Up to 50 | 47.2 | 14.4 | 26400 - 50600 |
| KLR-600 | 35.4 | 43.3 (Up to 157) | - | 15 | 2200 | Up to 50 | 59 | 18.5 | 28600 - 52800 |
Mill Turn Lathes - KLM Series
| Model | Mill-Turn | Max Turning Diameter (inches) | Max Turning Length (inches) | Spindle Through Hole (inches) | Chuck (inches) |
|---|---|---|---|---|---|
| KLM-300Y | Yes | 16.8 | 24.2 | 2.95 | 10 |
| KLM-300LY | Yes | 17.7 / 14.7 | 44.8 | 2.95 | 10 |
| KLM-300SY | Yes | 18.5 / 14.8 | 24.2 / 24.2 | 2.95 | 10 |
Sub Spindle Lathes - KLM Series
| Model | Sub-Spindle | Max Turning Diameter (inches) | Max Turning Length (inches) | Spindle Through Hole (Main / Sub) (inches) | Chuck (Main / Sub) (inches) |
|---|---|---|---|---|---|
| KLM-200S | Yes | 10.2 | 19.5 | 2.04 / 1.77 | 8 / 6 |
| KLM-200SM | Yes | 11.3 | 19.5 | 2.04 / 1.77 | 8 / 6 |
| KLM-300SM | Yes | 16.5 | 24 | 2.95 / 1.77 | 10 / 6 |
Large Bore Turning Lathes - KA Series
| Model | Swing Over Bed (inches) | Max Turning Length (inches) | Spindle Bore (inches) | Spindle Speed (RPM) | Spindle Motor (HP) | Machine Weight (tons) |
|---|---|---|---|---|---|---|
| KA-30 | 30 | 52 (Opt. up to 210) | 4 (Opt. up to 12) | 6-100 (Opt. 5-400) | 25/30 (Opt. 30/35) | 20 - 24 |
| KA-34 | 34 | 52 (Opt. up to 210) | 4 (Opt. up to 12) | 6-100 (Opt. 5-400) | 25/30 (Opt. 30/35) | 20 - 24 |
Key Features and Capabilities
- High Precision: Kent CNC machines are known for their exceptional accuracy, ensuring high-quality parts with tight tolerances.
- Advanced Control Systems: Integration of sophisticated CNC technology, ensuring precise machining and ease of operation.
- Robust Construction: Built with high-quality materials, Kent CNC machines are designed to withstand heavy use and provide long-term reliability.
- Versatility: Capable of handling a wide range of materials and applications, making them suitable for various industries.
- Efficiency: Designed to maximize productivity with features like automatic tool replacement, programmable cutting cycles, and energy-efficient operation.
Contact Information
Kent CNC is dedicated to providing exceptional customer support and service. For any inquiries, technical assistance, or support, please contact Kent CNC at:
Support Contact:
Phone: +1 (714) 258-8526
Email: sales@kentusa.com
Headquarters:
Kent CNC, 1231 Edinger Ave., Tustin, CA 92780, USA
For more information about Kent CNC and their offerings, visit their official website.
