Seller Needs:
$131,500|
1167
|
0
Situated in Texas and immediately available for purchase is a used 2002 DMG DMC 125 U LS5 Horizontal Machining Center. The respected owner asserts the machine is in top-tier condition, presenting a superb opportunity for pros...Read More
Seller Needs:
Payment:
Specs:
X Axis Travel: 49.2"
Y Axis Travel: 34.6"
Z Axis Travel: 31.5"
Spindle Speed: 18,000 RPM
Spindle Taper: HSK-A63 CT
Spindle Motor: 37.5 HP
Rapid Rate Y Axis: 1,574 IPM
Rapid Rate X Axis: 1,574 IPM
Rapid Rate Z Axis: 1,574 IPM
Tool Changer: 180 ATC
Max Pallet Load: 3307 LBS
Max Workpiece Diameter: 49.2"
Max Workpiece Height: 48.42"
Max Spindle Torque: 89 lb/ft
Spindle Bearing Diameter Front/Rear: 3.15" / 2.16"
Max Tool Weight: 22 lbs
Max Tool Diameter: 3.94" / 6.3"
Max Tool Length: 17.72"
Pallet Size: 39.4" x 31.5"
Weight: 32,187 LBS
Y Axis Travel: 34.6"
Z Axis Travel: 31.5"
Spindle Speed: 18,000 RPM
Spindle Taper: HSK-A63 CT
Spindle Motor: 37.5 HP
Rapid Rate Y Axis: 1,574 IPM
Rapid Rate X Axis: 1,574 IPM
Rapid Rate Z Axis: 1,574 IPM
Tool Changer: 180 ATC
Max Pallet Load: 3307 LBS
Max Workpiece Diameter: 49.2"
Max Workpiece Height: 48.42"
Max Spindle Torque: 89 lb/ft
Spindle Bearing Diameter Front/Rear: 3.15" / 2.16"
Max Tool Weight: 22 lbs
Max Tool Diameter: 3.94" / 6.3"
Max Tool Length: 17.72"
Pallet Size: 39.4" x 31.5"
Weight: 32,187 LBS
Options:
Chip Conveyor
Probe
Coolant Thru Spindle
360,000 Full 4th
Pallet Pool/FMS
5 Axis
CNC MillPlus Control
Linear 5 Pallet Changer System (7 Pallets Total)
180 Tool Magazine
Probe
Coolant Thru Spindle
360,000 Full 4th
Pallet Pool/FMS
5 Axis
CNC MillPlus Control
Linear 5 Pallet Changer System (7 Pallets Total)
180 Tool Magazine
Seller:
JoeB630
Location:
TX
