Seller Needs:
$89,000|
753
|
0
This 2018 HG TECH LT6515 Laser is a top-grade machine using a Siemens CNC control system. This tool has a modern operating interface, known for its user-friendly design, making it easy to use. The CNC control ensures a high l...Read More
Seller Needs:
Payment:
Specs:
MACHINE SPECIFICATION LT6515
• ROUND TUBE DIAMETER: 7/8" to 7”
• SQUARE TUBE: 7/8" x 7/8” to 4-3/4” x 4-3/4”
• BAR LOAD LENGTH: 137” to 256” (11.4’ to 21.3’) (3.5 m to 6.5m)
• BAR UNLOAD MAX LENGTH: 39” (1.5m) UPGRADABLE TO 6.5m
• LASER POWER: IPG YLS-2000 FIBER RESONATOR
• MATERIAL TYPES: STAINLESS STEEL, MILD STEEL, ALUMINUM, COPPER, OTHER ALLOYS
• RAW MATERIAL BUNDLE WEIGHT CAPACITY: 6600 LBS (3000KG)
X-AXIS
0-6500mm RANGE +/- 0.05mm POSITION ACCURACY 90m/Min MAX RUNNING SPEED
Y-AXIS
0-200mm RANGE +/- 0.05mm POSITION ACCURACY 30m/Min MAX RUNNING SPEED
Z-AXIS
0-170mm RANGE +/- 0.05mm POSITION ACCURACY 30m/Min MAX RUNNING SPEED
ROTARY SPEED 540? /SEC
MACHINE EQUIPPED WITH
• IPG YLS-2000 FIBER RESONATOR
• PRECITEC 125MM LIGHTCUTTER HEAD
• SIEMENS CNC SERVO MOTORS AND CONTROL SYSTEM
• HG TECH FARLEY LASER SIM OPERATING SYSTEM
• DUST COLLECTOR
• CHILLER
• ROUND TUBE DIAMETER: 7/8" to 7”
• SQUARE TUBE: 7/8" x 7/8” to 4-3/4” x 4-3/4”
• BAR LOAD LENGTH: 137” to 256” (11.4’ to 21.3’) (3.5 m to 6.5m)
• BAR UNLOAD MAX LENGTH: 39” (1.5m) UPGRADABLE TO 6.5m
• LASER POWER: IPG YLS-2000 FIBER RESONATOR
• MATERIAL TYPES: STAINLESS STEEL, MILD STEEL, ALUMINUM, COPPER, OTHER ALLOYS
• RAW MATERIAL BUNDLE WEIGHT CAPACITY: 6600 LBS (3000KG)
X-AXIS
0-6500mm RANGE +/- 0.05mm POSITION ACCURACY 90m/Min MAX RUNNING SPEED
Y-AXIS
0-200mm RANGE +/- 0.05mm POSITION ACCURACY 30m/Min MAX RUNNING SPEED
Z-AXIS
0-170mm RANGE +/- 0.05mm POSITION ACCURACY 30m/Min MAX RUNNING SPEED
ROTARY SPEED 540? /SEC
MACHINE EQUIPPED WITH
• IPG YLS-2000 FIBER RESONATOR
• PRECITEC 125MM LIGHTCUTTER HEAD
• SIEMENS CNC SERVO MOTORS AND CONTROL SYSTEM
• HG TECH FARLEY LASER SIM OPERATING SYSTEM
• DUST COLLECTOR
• CHILLER
Seller:
AlbeM493
Location:
USA
